IP PROTECTION :IP 68 OPERATING TEMPERATURE :-40 °C / +100 °C SPECIAL FEATURES : • Reduced sealing available • Colors available : RAL 7035 RAL 7001 RAL 9005 MATERIAL : • Polyamide 6 - UL94 V2 • Halogen free • Seal : neoprene THREAD : Metric, PG, NPT CERTIFICATIONS : • IEC 62 444 • VDE : 40046804 • UL : E184471 • DNV : TAE00004VD
Type Klemområde Gevind længde M12 (2,0 - 6,5) 8 mm M16 (4,0 - 10,0) 8 mm M20 (6,0 - 12,0) 9 mm M25 (9,0 - 16,0) 11 mm M32 (11,0 - 21,0) 11 mm M40 (16,0 -28,0) 11 mm M50 (21,0 -34,5) 13 mm M63 (30,0 -44,5) 15 mm M75 (48,0 -62,0) 18 mm
